DC Converter Efficiency Assessment

The purpose of DC converter is to convert electrical energy, turning input DC power supply into AC power supply with variable frequency to drive AC motor and other loads.

Its operating principle is making DC power supply going through a rectifying-filtering process to generate DC voltage, and converting DC power supply into AC power supply with variable frequency and amplitude with an inverter. Comparing to traditional AC converter, DC converter has better accuracy and adjustable range.

In recent years, with new energy power generation gaining popularity and thriving, DC converter has become an integral and important part of new energy power generation system. Its conversion efficiency has been closely watched by enterprises and users. Establishing a proper DC converter measurement and efficiency assessment method can help companies understand the energy consumption of DC converter, provide evidence for customers to choose energy-efficient DC converter and offer technical support for enterprises and users monitoring the efficiency of DC converter.

The SPAW7000 High Precision Power Analysis Wavecorder offers seven power input units and two motor input channels. It also supports a combination of various power modules. The powerful instrument provides multi-channel input, high-speed sampling, real-time data display and waveform display to measure voltage, current, power, efficiency and other electric parameters of AC/DC converter, motor, transformer and other power converters.

Main Advantages

INNO's strong professional capabilities make its products more advantageous in related fields

± (0.01% of the reading + 0.02% of the range)

Simultaneous 7-harmonic independent analysis.Up to 500 harmonic analyses.

Application Scenarios

Wind power generation, PV power generation and energy storage
New energy vehicle and charging pile
3C industrial manufacturing (motor, converter, transformer, inverter)
Power supply and lighting industry
Rail transit industry
Smart manufacturing

INNO Instrument is committed to covering complex scenarios
in various fields across the entire industry with its products.
