A2

The A2 Arc Fusion Splicer from INNO Instrument is designed with a focus on enhancing the splicing experience for users.

Description

The A2 Arc Fusion Splicer from INNO Instrument is designed with a focus on enhancing the splicing experience for users. It incorporates technology that significantly reduces splicing and heating times. The device also features advanced methods for estimation and alignment, aimed at improving the accuracy of splice loss estimation. The design of the A2 combines simplicity with a modern aesthetic, supported by a complex internal structure and robust durability, ensuring suitability for various operating environments. Additionally, the A2 is equipped with a dynamic operation interface and an automatic splice mode, offering user-friendly convenience.

Firmware Updates

Version	Description	Download
V1.19	1. Improve accuracy of fiber error defection 2. Add Timer when Splice Quick mode is used in workbench 3. Improve MM fiber splicing performance 4. Update for synchronizing to the PC program 5. Add additional algorithm to check the status after splicing. 6. Improving loss estimation in huge attenuation 7. Improve battery indication status 8. Add factory menu 7-2 to control batter indicator level, 7-3 for battery indicator calibration switch 9. Add Thailand language 10. Add graphic adjustment after Arc calibration 11. Add Motor operation record system 12. Fix a bug, Error message is not appear when windproof cover is opened in the middle of splicing 13. Add feature of Time-lock function 14. Improve system operation speed 15. Improve graphic parameter adjustment 16. Add remaining arc count during the Stabilize electrode 17. Add a function to control monitor brightness with left & right arrow keypad 18. Add buzzer sound when splicing is failed.	Download V1.19

Firmware Update Instructions

Prepare USB driver that has "FAT types" of format.

Unzip the download file, and place "F119.bin" file into USB driver.

Upgrade file must be out of folder in USB driver.

A2
Latest version: V1.19
Stated Version	Can Upgrade To	Upgrade way	Requirement after an upgrade to the latest version
~ V1.12	Latest	"F119A.bin" into USB	1. Run "RESET" in system setting 2. Run all maintenance menu
V1.13 ~			No required any action

PC Software

Version	Description	Download
Port Driver (Windows 8, 10, 11, x64)		Download Port Driver (Windows 8, 10, 11, x64)

PC Program Instructions

Nothing to Display
