V20 MICROSCOPE
The Fiber Microscope is chiefly used in checking if the fiber end-face is clean. With the ability to display a clear image and the
double amplification function, the V20 is able to analyze the cleanliness of the fiber end-face.
Description
Importance of a clean connector end interface
It is an essential to utilize auto-analysis software to test the connector and assess its quality during the commissioning and installation of the fiber.
It is very important to save the verification records of the connector for future reference. End-to-end verification can be achieved by combining the connector test with the fiber verification. The following are displayed test images.
Convenient test capability with PC software
Such software is installed on a PC, connected easily by a USB 2.0 interface. This makes the operation convenient. The results can be analyzed through the following procedure: connecting the optical fiber to the device, adjusting the sharpness and then tapping “screenshot”
