VIEW12R
VIEW 12R Arc Fusion Splicer from INNO Instrument. View 12R adopts innovative product design and exquisite manufacturing technology so as to deliver unprecedented splicing experience to customers. The simple-but-trendy product design, sophisticated internal structure and reliable protective cover make the splicer be suitable for any operating environment. Dynamic operation interface and automatic splice mode provide users great convenience.
Description
View 12R, a ribbon splicer with the fully motorized clamp alignment system, is the most powerful
and state-of-the-art ribbon splicer in the market. Its advanced automatic clamp alignment system offers an accurate and dependable ribbon fiber splicing up to 12 fibers with double-tapping (Zoom in & out) and scrolling to the world’s highest magnification of 250x for ribbon splicer. The View 12R provides maximum work efficiency through the fast splicing & heating time, ultra-high battery capacity of 220 splice / heat cycles, and universal holder both for 250μm & 900μm single
Firmware & PC Software
| Version | Description | Specific Instructions | Download |
|---|---|---|---|
| 1.40 | Added Norwegian, Hebrew language support Updated Finnish language support Matured V1.xx series: added OM4, SOC and G657A2 splice modes, image save/export and video playback General improvements | If the currently installed firmware is V1.34 or earlier, use F12_sw_m6.bin and res.zip from the package on the USB root. From V1.35 onward, use the standard update.zip method. | Download 1.40 |
Firmware Update Instructions
| Update Instructions | |
| Prepare USB | Format a USB drive as FAT32. |
| Prepare file | The firmware archive must be named update.zip. If the downloaded ZIP has another filename, rename it to update.zip. Do not extract it unless the selected firmware version says otherwise. |
| Copy file | Place update.zip directly in the USB drive root (main directory) — not inside a folder. |
| Start upgrade | Insert the USB drive and start the software upgrade from the on-device menu. |
| Exceptions | If an Upgrade Method is shown for the selected firmware version, follow that method instead of the standard update.zip procedure. |
PC Program Instructions
Nothing to Display
